RFID drug label
RFID drug label
RFID Drug tag has great application potential in drug anti-counterfeiting and tracking and supply chain management. RFID technology is adopted to track each link of drug sales and record it in the database in real time, which greatly ensures the safety of
RFID Drug tag has great application potential in drug anti-counterfeiting and tracking and supply chain management. RFID technology is adopted to track each link of drug sales and record it in the database in real time, which greatly ensures the safety of
  RFID Drug tag has great application potential in drug anti-counterfeiting and tracking and supply chain management. RFID technology is adopted to track each link of drug sales and record it in the database in real time, which greatly ensures the safety of drugs in circulation. RFID drug management aims to use high and new technology to meet the safety supervision of special medicines, chemical reagent, prevent fake medicine, expired drugs, illegal drugs into the market, prompting "medical personnel" right medicine, to curb drug bidding up the prices and monopoly market of unhealthy phenomenon, improve the drug transport and storage environment condition monitoring, drug manufacturers can also dynamically monitor drug flow and sales through the system.
Technical parameters of RFID drug tag
Data storage: ≥ 10 years
Erasable times: ≥ 100,000 times
Operating temperature: -20℃ -75 ℃ (humidity: 20%~90%)
Storage temperature: -40-70℃ (humidity: 20%~90%)
Operating frequency: 860-960MHz, 13.56MHz
Antenna size: customer can choose
Communication protocol: IS014443A/ISO15693ISO/IEC 18000-6 - c EPC Class1 Gen2
Working mode: Passive
Surface materials: PET, PVC, coated paper, PP synthetic paper, thermal paper, Teslin
Reading and writing distance: over 8m (reading and writing appliance with corresponding power)
Packaging materials: coated paper (PET, PVC, coated paper, PP synthetic paper, thermal paper) + Inlay+ adhesive + release paper
Optional chips: LMPinJ (M4, M4E, MR6, M5), Alien(H3, H4), S50, FM1108, Ult series,  I-Code series, Ntag series
Process personalization: bar code, QR, serial number, chip code, write data, etc
Printing process: 4 colors printing, pantone printing, digital printing
Package description: packed in static electricity bag, 2000 pieces/roll, 6 rolls/box
